Mastering Spring Core – IoC & Dependency Injection (DI)



🌟 1. What is Spring Framework?

Spring Framework is a powerful, lightweight Java platform for building enterprise-grade applications. It provides a comprehensive infrastructure support for developing Java applications.

✅ Main Goals:

• Loose Coupling

• Easy Testing

• Better Code Maintainability

• Integration with Web, Security, AOP, ORM, and Microservices (via Spring Boot)

🌀 2. What is Inversion of Control (IoC)?

📌 Definition:

Inversion of Control means transferring the control of object creation and dependency management to the Spring container, instead of manually creating objects using new keyword.

#BCS403,#Object Oriented Programming with Java

---

📦 Real-Life Analogy:

• Without IoC: You go to a restaurant, go to the kitchen, cook food, serve yourself.

• With IoC: You sit at a table and order. Chef (Spring container) serves you everything — you just consume.

---

🔧 Before Spring (Tightly Coupled Code):

public class Car {

    Engine engine = new Engine(); // tightly coupled

}

🌱 With Spring IoC (Loose Coupling):

public class Car {

    private Engine engine;

    public Car(Engine engine) { // injected via constructor

        this.engine = engine;

    }

}

And Spring container injects it for you.

🔗 3. What is Dependency Injection (DI)?

📌 Definition:

Dependency Injection is a design pattern used to achieve IoC. The object’s dependencies are injected by the container, not created manually.

✅ Types of Dependency Injection in Spring:

Type	Description	Use Case
Constructor DI	Dependencies are passed via constructor	Immutable objects
Setter DI	Dependencies injected via setter method	Optional dependencies
Field DI	Using annotations (@Autowired)	Quick setup

1️⃣ Constructor Injection (Constructor DI)

📌 Best for: Immutable dependencies (dependencies that shouldn’t change after object creation).

 Code Example:

🧩 Engine.java

 package com.example;

public class Engine {

    public void start() {

        System.out.println("🚀 Engine started via Constructor DI");

    }

}

🚗 Car.java

package com.example;

public class Car {

    private Engine engine;

    // Constructor DI

    public Car(Engine engine) {

        this.engine = engine;

    }

    public void drive() {

        engine.start();

        System.out.println("🏎️ Car is moving...");

    }

}

⚙️ applicationContext.xml

<bean id="engine" class="com.example.Engine"/>
<bean id="car" class="com.example.Car">
    <constructor-arg ref="engine"/>
</bean>

▶️ Output:
🚀 Engine started via Constructor DI
🏎️ Car is moving...

2️⃣ Setter Injection (Setter DI)
📌 Best for: Optional or changeable dependencies
 Code Example:

🧩 Engine.java
package com.example;
public class Engine {
    public void start() {
        System.out.println("🚀 Engine started via Setter DI");
    }
}
🚗 Car.java
package com.example;

public class Car {
    private Engine engine;

    // Setter Method for Injection
    public void setEngine(Engine engine) {
        this.engine = engine;
    }

    public void drive() {
        engine.start();
        System.out.println("🏎️ Car is moving...");
    }
}

⚙️ applicationContext.xml
<bean id="engine" class="com.example.Engine"/>
<bean id="car" class="com.example.Car">
    <property name="engine" ref="engine"/>
</bean>

▶️ Output:
🚀 Engine started via Setter DI
🏎️ Car is moving...

3️⃣ Field Injection (Annotation-Based @Autowired)
📌 Best for: Quick setup; not best for testing or immutability
Code Example:
🧩 Engine.java
package com.example;

import org.springframework.stereotype.Component;
@Component
public class Engine {
    public void start() {
        System.out.println("🚀 Engine started via Field DI");
    }
}

🚗 Car.java

package com.example;

import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Component;
@Component
public class Car {
    @Autowired
    private Engine engine;  // Field Injection
    public void drive() {
        engine.start();
        System.out.println("🏎️ Car is moving...");
    }
}

📄 Java Config – AppConfig.java
package com.example;

import org.springframework.context.annotation.ComponentScan;
import org.springframework.context.annotation.Configuration;
@Configuration
@ComponentScan("com.example")
public class AppConfig {}

▶️ Main Class – App.java
package com.example;

import org.springframework.context.ApplicationContext;
import org.springframework.context.annotation.AnnotationConfigApplicationContext;
public class App {
    public static void main(String[] args) {
        ApplicationContext context = new AnnotationConfigApplicationContext(AppConfig.class);
        Car car = context.getBean(Car.class);
        car.drive();
    }
}

▶️ Output:
🚀 Engine started via Field DI
🏎️ Car is moving...
🔍 Summary Table




DI Type
Config Style
Benefits
     Drawbacks




Constructor DI
XML / Java Config
Immutable, recommended for required deps
   More verbose if too many         dependencies




Setter DI
XML / Java Config
Good for optional properties
   Allows mutation (not ideal for all cases)




Field DI
Annotation-based
Short and clean
 Difficult to test, not           recommended for large apps



📘 4. How Spring Manages IoC and DI?
🔧 Spring provides a container called ApplicationContext, which:
Manages Beans
Injects Dependencies
Controls Bean Lifecycle
⚙️ 5. Let's Build a Simple Spring Core Project (Step-by-Step)
✅ Project Goal: Inject Engine object into Car using Spring
🛠 Step-by-Step (XML + Annotation Based DI)
🔶 STEP 1: Open Spring Initializr
Go to: 👉 https://start.spring.io
This is an official tool by Spring to generate a ready-to-use Spring Boot project.

🔶 STEP 2: Fill in Project Metadata
Fill the following fields:

Field
  What to Fill
Project
  Maven
Language
  Java
Spring Boot
  Keep latest version (e.g., 3.2.x)
Group
  com.example
Artifact
  spring-di-example
Name
  spring-di-example
Description
  Spring Boot project to demonstrate DI
Packaging
  Jar
Java Version
  17 or 21 (based on your system/IDE)
🔶 STEP 3: Add Dependencies
Click on the “ADD DEPENDENCIES” button and add:

✅ Spring Web
✅ Spring Context
✅ Spring Boot DevTools (for hot reload in development)
🔶 STEP 4: Generate Project
Click the “GENERATE” button.
A .zip file will be downloaded → Unzip it on your computer.
🔶 STEP 5: Open Project in IDE
Open IntelliJ IDEA, VS Code, or Eclipse.
Select: File → Open → Navigate to unzipped folder → Open the folder
Wait for the project to load and Maven to finish downloading dependencies.
🔶 STEP 6: Create Your Java Classes
Inside src/main/java/com/example/springdiexample/, create these files:
📁 Project Structure:
spring-core-example/
 ├── pom.xml
 └── src/
     └── main/
         ├── java/com/example/
         │     ├── Engine.java
         │     ├── Car.java
         │     └── App.java
         └── resources/
               └── applicationContext.xml
📄 pom.xml

🔶 STEP 6: Create Your Java Classes
Inside src/main/java/com/example/springdiexample/, create these files:
📄 Engine.java
package com.example.springdiexample;

import org.springframework.stereotype.Component;
@Component
public class Engine {
    public void start() {
        System.out.println("🚀 Engine started via Constructor DI");
    }
}

📄 Car.java
package com.example.springdiexample;

import org.springframework.stereotype.Component;

@Component
public class Car {
    private final Engine engine;
    // Constructor-based DI
    public Car(Engine engine) {
        this.engine = engine;
    }
    public void drive() {
        engine.start();
        System.out.println("🏎️ Car is moving via Spring Boot DI...");
    }
}

🔶 STEP 7: Modify the Main Class
Open the auto-generated main class:
📄 SpringDiExampleApplication.java
package com.example.springdiexample;

import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.boot.CommandLineRunner;
import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;
@SpringBootApplication
public class SpringDiExampleApplication implements CommandLineRunner {
    @Autowired
    private Car car;
    public static void main(String[] args) {
        SpringApplication.run(SpringDiExampleApplication.class, args);
    }
    @Override
    public void run(String... args) {
        car.drive();  // This method runs after the app starts
    }
}

🔶 STEP 8: Run Your Application
Right-click on SpringDiExampleApplication.java
Select Run
✅ Output You’ll See in Console

🚀 Engine started via Constructor DI
🏎️ Car is moving via Spring Boot DI...

🎯 You Just Built a Spring Boot App!

And you used:
Spring Initializr to generate boilerplate code
@Component to register beans
Constructor Dependency Injection
@Autowired and CommandLineRunner to run code on startup




🔄 Quick Recap

Step
Task
1
Go to Spring Initializr
2
Fill metadata and dependencies
3
Generate and unzip project
4
Open in IDE
5
Create Engine, Car class
6
Modify main class with DI
7
Run and see output

🎯 Benefits of This Flow

Feature
Why it helps?
Spring Initializr
      No manual setup, production-ready base
@Component
      Bean auto-registration
Constructor DI
      Clean and testable
CommandLineRunner
      Code runs at startup – great for testing

📚 Important Interview/Exam Questions
What is Inversion of Control in Spring? Explain with example.
What are the types of Dependency Injection? Which is preferred and why?
Difference between BeanFactory and ApplicationContext?
What is the role of @Autowired?
How is Spring loosely coupled?
What is the difference between XML vs Annotation based configuration?
What is the life cycle of a Spring bean?
